Cudy - GS105 - 5P

Cudy GS105. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 1000 entries. Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.3. IEEE 802.3ab. IEEE 802.3u. IEEE 802.3x. DC input voltage: 5 V

Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Networking standards	IEEE 802.3. IEEE 802.3ab. IEEE 802.3u. IEEE 802.3x
Copper ethernet cabling technology	10BASE-T. 100BASE-TX. 1000BASE-TX
Cable types supported	Cat3. Cat4. Cat5. Cat5e. Cat6. Cat6+. Cat6a. Cat6e. Cat7. Cat7e. Cat8. Cat8.1
Feature	Manual
Ethernet LAN data rates	10.100.1000 Mbit/s
Switching capacity	10 Gbit/s
Throughput	7.44 Mpps
MAC address table	1000 entries
Jumbo frames	2000
Packet buffer memory	1 MB
Product colour	Black
LED indicators	Loop. Link. Power
Mean time between failures (MTBF)	100000 h
Power source	AC/DC
AC input voltage	100 - 240 V
DC input voltage	5 V
Operating temperature (T-T)	-10 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Operating altitude	0 - 3048 m
Width	100 mm
Depth	70 mm
Height	26 mm
Weight	200 g
Cables included	DC
Package type	Box
Package width	175 mm
Package depth	120 mm
Package height	63 mm
Package weight	400 g
Master (outer) case width	505 mm
Master (outer) case length	320 mm
Master (outer) case height	400 mm
Master (outer) case gross weight	17 kg
Products per master (outer) case	40 pc(s)
