DigitMX Power Supply - DMX-PSU1203C - 12V 3A
€16.00
Tax included
Input: 100-240V 50/60Hz; Output: 12V/2A; DC adjustment range: ±10%; Input voltages range: 90-245V AC 50-60Hz; Inrush current: 30-75A; Leakage current: <0.7mA/230V AC.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Power Supplies - Type | 12V DC Adaptor |
|---|---|
| Power Supplies - Output Current | 3 A |
Input: 100-240V 50/60Hz
Output: 12V/2A
DC adjustment range: ±10%
Input voltages range: 90-245V AC 50-60Hz
Inrush current: 30-75A
Leakage current: <0.7mA/230V AC
Output voltage: 12V
Output current: 3A
DC adjustment range: ±10%
Overload protection: 105%-135% rated output power
Over-voltage protection: 105%-135% hiccup mode, auto-recovery
Withstand voltage:
I/P-O/P: 3kV AC
I/P-FG: 1.5kV AC
O/P-F/G: 0.5kV AC
Working temperature: -20 to ±70°C
Certifications: CE, RoHS Directive-compliant, FCC
| Type | Compact |
| Voltage | 12V |
| Ampers | 3A |
| Current | 3A |
