Mercury CAT6A FTP Indoor Network Cable OFC 305m Grey - 808.032UK - CAT6A, FTP, Indoor, OFC, 305m, Grey
€280.50
Tax included
Cat6a FTP indoor network cable on a wooden drum, 305 m, oxygen-free copper twisted pair with PVC sheath and aluminium foil screen; marked at 1 m intervals.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Ethernet Cables - Length Range | Other |
|---|
Cat6a oxygen free copper twisted pair data cable with PVC sheath and individual pair aluminium foil screen. Supplied on a wooden drum reel and marked at 1 metre intervals. This cable is designed for high speed data transmission such as Gigabit Ethernet applications.
- AWG 23 oxygen free solid copper conductor
- Supplied on a sturdy wooden drum reel
- Passes Cat6a fluke test 100m at 500MHz
- Complies to TIA/EIA-568 Cat6a standard
- Conductor: Solid OFC
- Strands: 8 x 1/0.560mmØ ±2%
- Cable : diameter7.3±0.5mm
- Screen: Aluminium/Mylar foil
- Insulation: PE 1.330±0.05mmØ
- Sheath:PVC 0.55±0.05mm thickness
- Capacitance: <330pf/100m
- DC resistance @ 20°C: <9.38 Ohms/100m
- Impedance (100 to 250MHz): 100±15 Ohms
- Impedance (250 to 500MHz): 100±22 Ohms
- Return loss: >25.61dB
- Attenuation: <2.51dB
- NEXT: >103.94dB
- PSNEXT: >102dB
- ELFEXT: >110.68dB
- PSELFEXT: >108.56dB
- Phase delay: <428.1ns
- Colour: Grey
- Length: 305m
- Weight: 17.4kg
| Type | Cat6a |
| Cable Type | FTP |
| Conductor | Pure Copper |
| Environment | Indoor |
| Length | 305m |
| Colour | Grey |
