Citronic Amplifier - D4200 - 4x200W 4ohm Quad Power Class-D
€452.50
Tax included
Quad digital power amplifier in a lightweight 1U rack-mount design delivering 4 x 200W at 4 ohm with Class-D efficiency.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
- Quad digital power amplifier in a lightweight 1U rack-mountable format. An energy-efficient switch-mode power section and class-D amplification circuit delivers accurate power-on-demand to four independent speaker outputs.
- Proprietary cool guide technology provides stable temperature management for dependable operation. Each pair of output channels can be separately parallel switched or bridged as a full or part stereo amplifier configuration.
- For channel A, there is a switchable 120Hz low-pass filter for use with subwoofers and a channels C and D have a switchable stereo pair of 120Hz high pass filters to effectively focus power in full-range cabs operating as mid-tops in conjunction with sub-woofers.
- For permanent or mobile installations, the D-series offers an invaluable and flexible problem solver for audio designers and sound engineers.
- Switchable bridge or parallel mono modes
- Switchable high and low pass filters
- Configurable as a quad, stereo or 2.1 system
- Fully balanced audio signal path
- Full audio and power protection with peak limiter
- Output rms @ 4 Ohms 4 x 200W
- Output rms @ 8 Ohms 4 x 100W
- Bridge power @ 8 Ohms 2 x 400W (both pairs of channels bridged)
| Channels | Quad |
| Power (8ohm) | 4 x 100 |
| Power (4ohm) | 4 x 200 |
| Amplifier Class | Class D |
| Bridge Mode | Yes |
| Warranty | 3 Years |
