NVR2016H-16P VIGI POE+ NETWORK VIDEO RECORDER TP-LINK

NVR2016H-16P VIGI 16 CHANNEL PoE+ NETWORK VIDEO RECORDER TP-LINK IP Video Input: 16-Channel Incoming Bandwidth: 160 Mbps Outgoing Bandwidth: 160 Mbps HDMI Output Resolution: Resolution: 3840x2160/30Hz, 1920x1080/60Hz VGA Output Resolution: 1920x1080/60Hz Video Output Mode: HDMI and VGA Independent / Simultaneous Output Multi-View Display: 1/4/6/8/9/16 Audio Compression: G.711A/G.711U/G.726 Video Compression: H.265+/H.265/ H.264+/H.264 Record Resolution: 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Synchronous Playback: 16-Channel Capability: • 25fps: 10-ch @ 1080P • 30fps: 2-ch@8MP, 4-ch@5MP, 5-ch@4MP, 6-ch@3MP Record Mode: Manual Recording, Scheduling Recording, Motion Detection Recording Playback Mode: Instant Playback, Regular Playback, Tag Playback, Event Playback Backup Mode: Regular Backup, Video Clip Backup Playback Function: Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off Protocol: UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP, IPv6, SNMP Mobile Phone Access: Android, iOS Web Browser: Chrome (57+), Firefox (52+), Edge (91+), Safari (11+) Interoperability: ONVIF Profile S, CGI Network Interface: 1, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface USB Interface: 1 Front USB 2.0 Port, 1 Rear USB 3.0 Port Audio Interface: 1-ch RCA Input; 1-ch RCA Output Alarm In/Out: 6/4 Power: 1× DC Jack Reset Button: 1 eSATA: 1 HDMI: 1 VGA: 1 SATA: 2 SATA Interfaces Capacity: Up to 16 TB Capacity for Each HDD PoE Standard: 802.3at/af Compliant PoE Interface: 1-16, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface PoE Budget: 90 W Available for All PoE+ Ports, 30 W Max per Port Dimensions (W × D × H): 330 × 285 × 45 mm Power Supply: 53.5V DC / 2.43A Max. Power Consumption: 6.2 W (Without Disk), 40 W (With Disk)
