Gigabyte GA-B550M DS3H AC R2 - B550 Micro-ATX AM4 Motherboard, DDR4, 128GB Max, RGB, HDMI/DisplayPort
€114.50
Tax included
AM4 B550 micro-ATX motherboard for Ryzen 3000/4000/5000. 4x DDR4 slots up to 128GB, PCIe 4.0, M.2 support, HDMI + DisplayPort, Realtek Gigabit LAN, Wi‑Fi AC.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Motherboards - Memory Slots | 4 |
|---|---|
| Motherboards - Max Memory Capacity | 128 GB |
| Motherboards - PCIe Version | PCIe 4.0 |
| Motherboards - SATA Ports | 4 |
| Motherboards - USB-C Support | None |
| unterstützte Prozessormodelle | AMD Ryzen 3000 Series, AMD Ryzen 4000 Series, AMD Ryzen 5000 Series |
| Sockel | Sockel AM4 |
| Chipsatz | AMD B550 |
| BIOS | 128 Mbit |
| Formfaktor | micro ATX |
| geeignet für freien Multiplikator | ja |
| Speicher max. | 128 GB |
| Memory slots | 4 |
| Speicher je Speicherplatz | 32 GB |
| Storage type | DDR4-SDRAM |
| RAM Takt | 4733,4600,4400,4266,4133,4000,3866,3733,3600,3466,3400,3200,2933,2667,2400,2133 MHz |
| Speicher Kanäle | Zweikanalig |
| Speichertyp | ECC unbuffered;non-ECC unbuffered |
| Controller in CPU | ja |
| LAN (RJ45) | Gigabit Ethernet |
| PS/2 (Tastatur/Maus) | 1 |
| USB 3.1 | 0 |
| USB 3.0 | 4 |
| USB 2.0 | 2 |
| VGA | 0 |
| HDMI | 1 |
| DisplayPort | 1 |
| Mikrofon | 1 |
| Line-Out 3,5 mm Klinke | 4 |
| S/PDIF-Out (optisch) | 1 |
| PCIe 4.0 | 1 |
| PCIe 3.0 | 1 |
| Mainbord Strom | 24pin |
| CPU Strom | 8pin |
| SATA 3 | 4 |
| M.2 | 2 |
| M.2 Länge max. | 110mm |
| M.2 Konnektor | M |
| USB-Header USB 2.0 | 1 |
| USB-Header USB 3.0 | 2 |
| USB-Header USB C | 0 |
| Lüfter 4-polig PWM | 2 |
| Sound-Chip | 7.1 Kanäle |
| LAN | Realtek RTL8111H |
| Multi-GPU Modus | Nicht unterstützt |
| RAID SATA | 0, 1, 10 |
| Beleuchtungsfarbe | RGB LED |
| Farbe | schwarz |
| Gewicht (g) | 980 g |
| Breite (cm) | 30.50 |
| Tiefe (cm) | 24.40 |
| Internal graphic | yes |
| verfügbare Slots | 4 |
